CyberPower - CyberPower Office Rackmount LCD Series OR500LCDRM1U
UPS - 300 Watt - 500 VA - 7 Ah - RS-232, USB - output connectors: 6 - 1U
CyberPower
OR500LCDRM1U
N/A
20649532715019
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | CyberPower Office Rackmount LCD Series OR500LCDRM1U - UPS - 300 Watt - 500 VA |
| Device Type | UPS - external |
| Rack Size | 1U |
| Weight | 18.08 lbs |
| Output Voltage | AC 120 V ± 10% |
| Power Capacity | 300 Watt / 500 VA |
| Input Connectors | 1 x power NEMA 5-15 |
| Output connectors | 4 x power NEMA 5-15 (UPS and surge) ¦ 2 x power NEMA 5-15 (surge) |
| Battery | Lead acid - 7 Ah |
| Batteries Qty | 2 |
| Run Time (Up To) | 3 min at full load |
| Networking | RS-232, USB |
| Dimensions (WxDxH) | 17 in x 9.3 in x 1.7 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - external |
| Height (Rack Units) | 1U |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | Serial cable - external ¦ USB cable - external ¦ Power cable - integrated - 10 ft |
| Equipment Protection Value | 30000 US Dollars |
| Features | Audible alarm, LCD display, Automatic Voltage Regulation (AVR) |
| Compliant Standards | FCC Class B certified, cUL, UL 1778 |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Software / System Requirements | |
| Software Included | PowerPanel Plus |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% |
| Battery | |
| Quantity | 2 |
| Technology | Lead acid |
| Voltage Provided | 6 V |
| Capacity | 7 Ah |
| Run Time (Up To) | 3 min at full load |
| Recharge Time | 8 hours |
| Power Device | |
| UPS Technology | Line interactive |
| Supported Battery Technology | Lead acid |
| Input Voltage Range | AC 90 - 140 V |
| Frequency Provided | 60 Hz |
| Frequency Required | 60 Hz |
| Input Connectors | 1 x power NEMA 5-15 |
| Power Output Connectors Details | 4 x power NEMA 5-15 (UPS and surge) ¦ 2 x power NEMA 5-15 (surge) |
| Output Voltage | AC 120 V ± 10% - 60 Hz |
| Power Capacity | 300 Watt / 500 VA |
| Dataline Surge Protection | Network/phone line - RJ-45/RJ-11 |
| Output Waveform | Stepped approximation to a sinewave |
| Surge Energy Rating | 1030 Joules |
| Circuit Protection | Circuit breaker |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 9.3 in |
| Height | 1.7 in |
| Weight | 18.08 lbs |
